Provides Protection Against Water, Dust, and UV Rays!
The PMX-1 features a scratch resistant wet bonded display, superior Bluetooth® audio, AUX and USB inputs. The Element Ready™ design also provides protection against water, dust, and UV rays.
The PMX-1 features a 9H tempered glass screen optically bonded which allows for optimized viewing of the dot matrix display under all lighting and viewing conditions. The superior Bluetooth® audio features A2DP and AVRCP for better range, easier device pairing and glitch free wireless audio streaming. The flexible AUX and USB inputs enable convenient access to various audio playback formats and charging of your mobile devices.
Features:
- Wet bonded 2.3" Full Dot Matrix LCD Display
- 9H Tempered Glass Screen
- A2DP and AVRCP Bluetooth® Wireless Streaming
- AUX and USB Inputs with USB Charging
- Compatible with PMX-BTUR Steering Wheel Remote
- Independent Subwoofer Level Control
- 7-Band Graphic EQ + PEQ
- Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
- Voltage gauge with Low voltage Warning
- AM / FM / WB Tuner
- Multi Region Radio Frequencies
- IP6 Marine Grade Front Panel
- FCC, CE and EN60945 Certified
Specifications:
- Bluetooth® (Yes/No) Yes, 3.0+EDR, A2DP 1.3
- Speaker Outputs (Yes/No) Yes
- Device Type Digital-Media Receiver
- Multi-Zone/Multi-Source (Yes/No) No
- Pandora® Internet Radio (Yes/No) No
- SiriusXM-Ready® (Yes/No) No
- AUX Input (Yes/No) Yes (1 RCA pair)
- USB Charging (Yes/No) Yes
- Clock (Yes/No) No
- Steering Wheel Control Ready (Yes/No) No
- TUNER Number Of Presets 18 FM / 12 AM / 6 WB
-
AM Tuner
Range: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 KHz -
FM Tuner
Range: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response. 20 - 15 KHz -
Power Output (max)
CEA-2006 GuidelinesCEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω MAX
≤1.0% THD+N -
Frequency Response
RCA: 20 Hz - 20 kHz
High-Level: 20 Hz - 20 kHz - Min. Speaker Impedanc e2Ω
- Output Impedance <500 Ω
-
Max Output Voltage
RCA Front: 2 V
RCA Rear/Sub: 2 V -
Media Formats
MP3 - WMA
-
Signal to Noise Ratio
RCA 2V: >85 dB
High-Level CEA-2006: >75 dB
High-Level Max Watts: >85 dB -
Channel Separation
RCA: >70 dB - High-Level: >50 dB
- Compatible Remotes N/A
- Max THD+N High-Level: <1.0 @ 4-Ohm
- USB Output Current 1 A
- Operating Voltage 9 - 16 VDC
- USB Version 2.0
- Idle Current <2 A
- Fuse Rating 20 A
-
Dimensions
Width: 4.5" (11.5 cm)
Face Depth: 1.5" (3.8 cm)
Mount Depth: 2.9" (7.4 cm)
Height: 4.2 (10.6 cm) - Shipping Weight 1.22 Lbs. (0.55 Kg)
- Back Panel Cutout 3" (77 mm)
