Rockford Fosgate PMX-0 Punch Marine Ultra Compact Digital Media Receiver

Sale price $349.00 Regular price $429.00

The Rockford Fosgate PMX-0 Punch Marine Ultra Compact Digital Media Receiver is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front-mounted sublevel controls.

It features Bluetooth audio streaming for Apple and Android products as well as auxiliary audio input and is the ideal choice for that small system media receiver. The PMX-0 is a ground up designed ultra compact digital media receiver ideal for small systems and vehicles. This unit Features Bluetooth streaming audio connectivity for both Apple and Android-based devices, RCA Auxiliary inputs as well as Front, Rear and Sub RCA output connections. Control is provided through the water-resistant rotary encoder knob and white LED backlit buttons and provide instant sublevel control at your fingertips.

The front panel is IPX6 rated for water spray intrusion and features a conformal coated PCB circuit board protecting the vital electronics. We further validate the unit with 500 hours of testing under both the ASTM B117 and D4329 testing standards to make sure it will hold up under years of daily use exposed to the elements.



Main Features:

  • Bluetooth streaming audio (A2DP) protocol version 1.0 installed
  • Simple Secure Pairing (SSP)
  • Front Panel Sub Control
  • White LED Button Illumination
  • Waterproof Rotary Encoder Volume Control
  • Voice Command Confirmation
  • Epoxy coated circuit board for water resistance
  • Rear AUX-In (L/R)
  • Rear USB With 1A Charging Only
  • Upgradeable Firmware and Bluetooth Software via USB
  • Easy 2″ Mounting Hole and Compression U-Clamp Mounting
Pmx 0 Image5

Specifications

Weight - 0.52 kg
Dimensions - N/A
Model - PMX-0
Warranty - 2 years
Operating Voltage - 10.5 – 16 Volts
Made For IPod Models - Bluetooth® Only
Speaker Outputs (Yes/No) - No
Power Output - No
Fuse Rating - 3 A
USB Capacity - No
Android Compatibility - Bluetooth® Only
Device Type - Digital-Media Receiver
Bluetooth® (Yes/No) - Yes 3.0, AVRCP & A2DP

Pandora® Internet Radio (Yes/No) - No

SiriusXM Ready® (Yes/No) - No
USB Charging (Yes/No) - Yes
USB Version - No
USB Output Current - 1A (Charging Only)
Made For IPhone Models - Bluetooth® Only
Apple®/Android™ Compatible (Yes/No) - Yes
RCA Output Voltage - 2 V
Multi Zone/Multi Source (Yes/No) - No
Depth - 2.5″ (3.35 cm)
Faceplate - Depth: 1.5″ (3.81 cm)
Chassis - Depth: 1.0″ (2.54 cm)
RCA Output Impedance - 500Ω
Clock (Yes/No) - No
Speaker Output THD+N - <1.0
Frequency Response - 20Hz-20Khz
AUX Input (Yes/No) - Yes
Steering Wheel Control Ready (Yes/No) - No
Back Panel Cutout - 2″ (52 mm)
